Parameters of 58MW Biomass Hot Water Boiler

2021-06-22 10:56:16

58MW biomass hot water boiler has an "n" layout as a whole, consisting of a Φ1600mm boiler drum, a water wall in the furnace, an external downcomer, a large scale chain grate, two sets of economizers and a tubular air preheater. The boiler has the characteristics of high thermal efficiency, low operating cost, long-term trouble-free operation, low smoke and dust emission at the outlet of the boiler, light weight, low capital investment, chip package delivery, small on-site installation workload, short installation cycle, etc. It is a large capacity in my country. Alternative products for hot water boilers.


DHL58-1.6-130/70-T biomass hot water boiler can be used as a heat source host for central heating in cities and industrial and mining enterprises. The heating area of a single unit can reach 600,000-800000 m². It can also be used for industrial and mining enterprises that require a large amount of process hot water. Meet its needs.

The main parameters of 58 MW biomass hot water boiler are as follows:

Model DHL58-1.6-130/70-T Brand ZBG
Rated Thermal Power 58MW Rated Pressure 1.6 MPa
Water Outlet Temp. 130℃ Water Inlet Temp. 70℃
Fuel Coal & Biomass Thermal Efficiency 80%-83.5%

Want to know more details about 58 mw biomass hot water boiler? Welcome to consult online customer service, or directly call +86 17719993430, ZBG Boiler will serve you wholeheartedly!
