DZL Series Coal Fired Chain Grate Boiler

Overview

Brief Introduction:

DZL series packaged chain grate boiler adopts patented design double wings gas ducts structure and inverted "α" arch furnace technology, which is widely used with its advantages of simple installation, low initial investment, safe and reliable operation, energy conservation, environmental protection, etc.

Application:

Thermal power plant, heating company, food & beverage, cement plant, paper mill, chemical industry, pharmaceuticals industry, textile industry, coal industry, steel & iron industry, non-ferrous metallurgy, mining industry.

Features:

• New furnace structure, bulge defects caused by the bottom of the drum being heated directly is avoided.
• Patented design double wings gas ducts structure, flue tube plate crack is avoided.
• Inverted "α" arch furnace technology makes the front arch high and short, rear arch low and long, the combustion efficiency is improved.
• Special furnace design make different kinds of fuel is available.
• Independent adjustable wind chamber under the fire grate, and wind comes from two sides. Ventilated section ratio reaches 100% , and can be adjusted flexibly and air flows evenly.
• Push-pull type damper ash removal device effectively prevents deformation of the secondary combustion and grate air leakage.

Parameters
