Two 500 BHP Oil Steam Boilers With the ASME Stamp

 We have a Project in Ecuador to provide Two 500 BHP steam boilers.

• 3 pass
• Dryback
• Operating pressure: 200 PSIG
• Design pressure: 220 PSIG
• They well work with fuel oil #2
• We Will provide the burners
• Must have ASME stamp
• Altitude: 0 fasl

Please let me know if you are able to quote both boilers with the ASME stamp. We need this asap, let me know if you need further information.

steam boiler

Two 500 BHP Oil Steam Boilers

The unit used to express capacity is different in each country. How many tons is 500 BHP? Calculating based on 1 t/h = 71.1BHP, we can roughly calculate that a 500 BHP oil-fired boiler is equivalent to a 7t/h oil-fired boiler. Pressure 200 PSIG = 1.3789514mpa Design pressure 200 PSIG is approximately equal to 1.5 mpa.

Technical parameters of 7 tons/hour steam boiler

1. Rated evaporation capacity: 500 BHP(7 t/h )
2. Boiler model: WNS7-1.6-YQ, SZS7-1.6-YQ
3. Rated steam pressure: 1.6MPA
4. Rated steam temperature: 204℃
5. Water supply temperature: 20℃
6. Applicable fuel: light diesel, heavy oil
7. Factory way: quick install
8. Diesel fuel consumption: 445kg/h

The boilers produced by our company include not only 7 tons gas-fired boilers, but also biomass boilers, coal fired boilers, circulating fluidized bed boilers, waste heat boilers and so on, with capacity ranging from 1 ton to 410 tons, product dimensions and equipment levels are tailored to the customer's individual needs.
